Dell XPS 210 - Manual (Page 17)

1. Follow the procedures in Before You Begin .
2. Pull up on the drive release latch and slide the drive towards the back of the computer.
3. Carefully, lift the drive away from the computer.
4. Disconnect the data cable from the CD/DVD connector on the system board (see System Board Components ).
5. Disconnect the power cable and data cable from the back of the drive.
6. Set the drive aside in a secure location.
Installing a CD/DVD Drive
1. Follow the procedures in Before You Begin .
2. Unpack the drive and prepare it for installation.
Check the documentation that accompanied the drive to verify that the drive is configured for your computer.
3. Connect the power and data cables to the drive.
NOTICE: Do not pull the drive out of the computer by the drive cables. Doing so may cause damage to the cables and cable connectors.
1 drive release latch 2 CD/DVD drive
1 data cable 2 power cable 3 CD/DVD connector
4 CD/DVD drive 5 CD/DVD drive bracket
