Getting Started With Your System
15
PowerConnect 5316M Ethernet Switch Module
Externally accessible connectors
Gb 10/100/1000 Mbps Ethernet Six autonegotiating RJ-45 uplinks
Physical
Height 3.302 cm (1.3 in)
Width 13.081 cm (5.15 in)
Depth 27.432 cm (10.8 in)
Weight 0.816 kg (1.8 lb)
Gb Ethernet Pass-Through Module
Externally accessible connectors
Ethernet Ten RJ-45 uplinks (for integrated 1-Gbps NICs)
NOTE:
Pass-through uplinks support 1000 Mbps
connection only.
Physical
Height 3.302 cm (1.3 in)
Width 13.081 cm (5.15 in)
Depth 27.432 cm (10.8 in)
Weight 0.816 kg (1.8 lb)
Fibre Channel Pass-Through Module
Externally accessible connectors
Fibre Channel transceiver Ten 76-pin, 3.5 Gbps, GPI0 transceiver
receptacles
Physical
Height 3.302 cm (1.3 in)
Width 13.081 cm (5.15 in)
Depth 27.432 cm (10.8 in)
Weight 0.816 kg (1.8 lb)
