Dell PowerEdge SC 440 - Manual (Page 11)

Getting Started With Your System
9
Tape drive one optional internal half-height, 5.25-inch SATA
(for use in 5.25-inch bay only)
Flash drive external optional USB
Connectors
Back
NIC one RJ-45 (for integrated 1-Gigabit NIC)
Serial 9-pin, DTE, 16550-compatible
USB five 4-pin, USB 2.0-compliant
Video 15-pin VGA
Front
USB two 4-pin, USB 2.0-compliant
Internally accessible
IDE channel 40-pin
SATA channels Four 7-pin
Video
Video type Integrated
Video memory 16 MB
Power
AC power supply (per power supply)
Wattage 305 W
Voltage 115–230 VAC, 60/50 Hz, 9.0-4.5 A
Heat dissipation 1040 BTU/Hour
CMOS Backup Battery CR 2032 3.0-V lithium ion coin cell
Physical
Height 44.8 cm (17.6 in)
Width 17.1 cm (6.8 in)
Depth 46.7 cm (18.4 in)
Weight (maximum configuration) 17.7 kg (39 lb)
Drives (continued)
