ASRock Z87 Extreme9__ac User Manual
Page 19
16
17
English
Z87 Extreme9/ac
Installing the ASRock Wi-SD Box
Step 1
Prepare the bundled ASRock Wi-SD Box and
screws.
Step 2
Plug the Front USB 3.0 cable into the USB 3.0
header on the Wi-SD Box.
Step 3
If you have 2.5” HDD/SSDs, you may insert up
to two and secure them in ASRock Wi-SD Box
with screws.
Step4
Install ASRock Wi-SD Box into the drive bay of
the chassis.
Wi-S
D
Wi-S
D
Wi-S
D
