English
Storage • 2 x SATA3 6.0 Gb/s connectors, support NCQ, AHCI and Hot
Plug
• 1 x eSATA connector, supports NCQ, AHCI and Hot Plug
Connector • 1 x Chassis Intrusion header
• 1 x TPM header
• 1 x CPU Fan connector (4-pin)
• 1 x Chassis Fan connector (4-pin)
• 1 x 24 pin ATX power connector
• 1 x 4 pin 12V power connector
• 1 x Front panel audio connector
• 1 x USB 2.0 header (supports 2 USB 2.0 ports)
BIOS
Feature • 32Mb AMI UEFI Legal BIOS with Multilingual GUI support
• ACPI 1.1 Compliance Wake Up Events
• SMBIOS 2.3.1 Support
• CPU, DRAM, PCH 1.05V, PCH 1.5V Voltage Multi-adjust-
ment
Support
CD • Drivers, Utilities, AntiVirus Software (Trial Version),
CyberLink MediaEspresso 6.5 Trial, Google Chrome Browser
and Toolbar, Start8 (30 days trial)
Hardware
Monitor • CPU/Chassis Temperature Sensing
• CPU/Chassis Tachometer
• CPU/Chassis Quiet Fan (Allow Chassis Fan Speed Auto-
Adjust by CPU Temperature)
• CPU/Chassis Fan Multi-Speed Control
• CASE OPEN detection
• Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore
OS • Microsoft® Windows® 8 / 8 64-bit / 7 / 7 64-bit compliant
Certifica-
tions • FCC, CE, WHQL
• ErP/EuP Ready (ErP/EuP ready power supply is required)
