8 9
English
Z87M OC Formula
Storage • 6 x SATA3 6.0 Gb/s connectors, support RAID (RAID 0,
RAID 1, RAID 5, RAID 10, Intel Rapid Storage Technology
12 and Intel Smart Response Technology), NCQ, AHCI and
Hot Plug
• 1 x eSATA connector, support RAID (RAID 0, RAID 1,
RAID 5, RAID 10, Intel Rapid Storage Technology 12 and
Intel Smart Response Technology), NCQ, AHCI and Hot Plug
* eSATA Connector is shared with the SATA3_1 port.
Connector • 1 x IR header
• 1 x COM port header
• 1 x Power LED header
• 2 x CPU Fan connectors (1 x 4-pin, 1 x 3-pin)
• 3 x Chassis Fan connectors (1 x 4-pin, 2 x 3-pin)
• 1 x Power Fan connector (3-pin)
• 1 x 24 pin ATX power connector
• 1 x 8 pin 12V power connectors
(Hi-Density Power Connector)
• 1 x Front panel audio connector
• 2 x USB 2.0 headers (support 4 USB 2.0 ports)
• 1 x Vertical Type A USB 2.0
• 1 x USB 3.0 header (supports 2 USB 3.0 ports)
• 1 x Power Switch with LED
• 1 x Reset Switch with LED
• 1 x Clear CMOS Button
• 1 x Post Status Checker (PSC)
• 1 x Slow Mode Switch
• 1 x LN2 Mode Switch
• 1 x BIOS Selection Switch
BIOS
Feature • 2 x 64Mb AMI UEFI Legal BIOS with Multilingual GUI sup-
port (1 x Main BIOS and 1 x Backup BIOS)
• Supports Secure Backup UEFI Technology
• ACPI 1.1 Compliance Wake Up Events
• SMBIOS 2.3.1 Support
• CPU, DRAM, PCH 1.05V, PCH 1.5V Voltage Multi-adjust-
ment
