English
Z87M OC Formula
Audio • 7.1 CH HD Audio with Content Protection (Realtek ALC1150
Audio Codec)
• Premium Blu-ray audio support
• Supports Purity Sound™
- 115dB SNR DAC with differential amplifier
- TI® NE5532 Premium Headset Amplifier (supports up to
600 Ohms headsets)
- Direct Drive Technology
- EMI shielding cover
- PCB isolate shielding
• Supports DTS Connect
LAN • Gigabit LAN 10/100/1000 Mb/s
• Giga PHY Intel® I217V
• Supports Intell® Remote Wake Technology
• Supports Wake-On-LAN
• Supports Energy Efficient Ethernet 802.3az
• Supports PXE
Rear Panel
I/O • 1 x PS/2 Mouse/Keyboard Port
• 1 x HDMI-Out Port
• 1 x HDMI-In Port
• 1 x DisplayPort
• 1 x Optical SPDIF Out Port
• 1 x eSATA Connector
• 2 x USB 2.0 Ports
• 4 x USB 3.0 Ports (Intel® Z87) (ASMedia Hub)
• 2 x USB 3.0 Ports (Intel® Z87)
• 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED
LED)
• 1 x Clear CMOS Button
• HD Audio Jack: Rear Speaker / Central / Bass / Line in / Front
Speaker / Microphone
