ACU-RITE SENC 50 User Manual
Page 3
Page
Introduction / Supplied items ............................................... 2
Key Points / Tolerances ......................................................... 3
Linear Encoder Dimensions .................................................. 4
Spar Dimensions .................................................................... 5
Mounting Requirements ........................................................ 6
Typical Mounting ................................................................... 7
Encoder Installation Procedure ............................................ 8
Page
Checking the Installation .................................................... 10
Electrical Shielding .............................................................. 11
Troubleshooting ................................................................... 12
Mechanical Specifications ................................................... 13
Output Signals and Pin-Outs .............................................. 14
Electrical Specifications ...................................................... 15
The Acu-Rite Companies Inc.
Hassle Free Warranty & Service ........................................ 16
SENC 50
Table of Contents
• Installation brackets and kits are available.
• Your Authorized Distributor can assist you in selecting
brackets and tools for your installation.
1
Acu-Rite Companies Inc.
Front mount
bracket
Adjustable front or
rear mount
Bottom mount
bracket
Base mount
Front mount
bracket
Spar
