294
uu Replacing Light Bulbs u Daytime Running Light Bulbs
Ma
inte
na
n
ce
Daytime Running Light Bulbs
When replacing, use the following bulbs.
1. Driver side: Remove the holding clips by
pushing the center of the clips.
Lift the grommet over the stud bolt and
rotate the heat shield to the left.
Passenger side: Remove the power
steering fluid reservoir by pulling it out of its
stay.
2. Remove the bulkhead cover and engine
compartment covers.
2 Engine Compartment Covers P. 279
3. Remove the coupler.
u It can be removed by pushing the tab.
4. Rotate the old bulb to the left to remove.
5. Insert a new bulb into hole and turn it to
the right.
6. Insert the coupler into the connector of the
bulb.
Side Turn Signal/Emergency Indicator Light Bulbs
Door mirrors have the side turn lights. Have an authorized Acura dealer inspect and
replace the light bulbs.
Daytime Running Light: 60 W
Clip
Heat Shield
Grommet
Stud Bolt
Bulb
Tab
Coupler
