252
uu Replacing Light Bulbs u Front Turn Signal/Parking/Side Marker Light Bulbs
Main
tenan
ce
2. Remove the coupler.
u It can be removed by pushing the tab.
3. Rotate the old bulb to the left to remove.
4. Insert a new bulb into the fog light
assembly and turn it to the right.
5. Insert the coupler into the connector of the
bulb.
Front Turn Signal/Parking/Side Marker Light Bulbs
When replacing, use the following bulbs.
Turn the steering wheel and pull the inner fender back in the same way as when
replacing the low beam headlights.
2 Changing the Low Beam Headlight P. 250
1. Turn the socket to the left and remove it.
2. Push in the old bulb, rotate to the left until
it unlocks, and remove.
3. Insert a new bulb.
Bulb
Coupler
Tab
Front Turn Signal/Parking/Side Marker: 21/5W
Socket
Bulb
