Acura 2012 TSX User Manual
Page 252
uu
Replacing Light Bulbs
u
Headlight Bulbs
250
Main
tenan
ce
High voltage can remain in the circuit for a long period of time after the light is
switched off. Do not attempt to inspect or replace the high voltage discharge type
bulbs yourself. Ask a dealer to inspect and replace low beam headlights.
1. Turn the steering wheel all the way to the
opposite side from the headlight being
replaced.
Passenger side: Turn the steering wheel to
the left.
Driver side: Turn the steering wheel to the
right.
2. Remove the holding clips and screws, and
pull the inner fender back.
3. Rotate the cover to the left, and remove.
■
Low Beam Headlights
■
Low Beam Headlights
High Voltage Discharge Types
Halogen Types
1
Insert a flat-tip screwdriver, lift and remove the
central pin to remove the clip.
Inner Fender
Cover
Screw
Clip
