3. Remove the blade from the blade
assembly:
●
Find two tabs with a ‘‘SET’’ and
‘‘ ’’ mark on the wiper blade
assembly. The opposite side of
the
‘‘ ’’ mark is the direction
you pull out the wiper blade.
● Pull out the blade by grabbing
the end of it as shown in the
above illustration.
4. Examine the new wiper blades. If
they have no plastic or metal
reinforcement along the back
edge, remove the metal
reinforcement strips from the old
wiper blade, and install them in the
slots along the edge of the new
blade.
5. Install the new blade onto the
blade assembly:
●
Find two tabs with a ‘‘SET’’ and
‘‘ ’’ mark on the wiper blade
assembly. This is the direction
you install.
●
Slide the blade onto the
assembly until it is locked by the
tabs.
BLADE
BLADE
REINFORCEMENT
TABS
CONTINUED
Wiper Blades
441
Maintenance
