3. Remove the electrical connector
from the bulb by pushing on the
tab and pulling the connector
down.
4. Remove the bulb from the fog light
assembly by turning it one-quarter
turn counterclockwise.
5. Install the new bulb into the hole
and turn it one-quarter turn
clockwise to lock it in place.
6. Push the electrical connector back
onto the bulb. Make sure it is on
all the way.
7. Turn on the fog lights to test the
new bulb.
8. Put the undercover in place.
Reinstall the clip, and tighten the
screw securely.
Replacing a High-mount Brake
Light Bulb
1. Remove the two screw covers on
the light assembly by prying on
the side edge with a flat-tip
screwdriver.
2. Remove the screws with a Phillips-
head screwdriver, then remove the
light assembly from the tailgate.
CONNECTOR
BULB
SCREWS
COVERS
Lights
436
