Page 25
SECTION 5—BACK
Part No.1125095
25
Replacing Back Upholstery
NOTE: For this procedure, refer to FIGURE 5.2.
1. Remove the screws and washers that secure the existing back upholstery to the back
canes.
2. Position new back upholstery on back canes.
3. Securely tighten the new back upholstery to the back canes with the screws and
washers.
FIGURE 5.2 Replacing Back Upholstery
Replacing Seat Upholstery
NOTE: For this procedure, refer to FIGURE 5.3.
1. Remove the screws that secure the existing seat upholstery to the crossbraces.
2. Remove the existing seat upholstery from the crossbraces.
3. Install the new seat upholstery by reversing STEPS 1-2.
FIGURE 5.3 Replacing Seat Upholstery
Screws
Back Upholstery
Washer
Washer
NOTE: Back upholstery shown is for the Transport and the Lightweight Transport. The Lite
Transport has 10 screws and washers. The Bariatric Transport has 16 screws and washers.
Seat Upholstery
Screws
NOTE: Seat upholstery shown is for
the Transport, the Lightweight
Transport, and the Lite Transport.
The Bariatric Transport has 14
