Trouble shooting and specification – Activeforever Image EC Mid Wheel Drive Reclining Power Wheelchair User Manual
Page 26
25
8. TROUBLE SHOOTING AND SPECIFICATION
SPECIFICTIONS
MODEL
ITEM
IMAGE EC
Dimension (L×W×H )
41.75” x 24.6” x 43.25” / 1060x625x1100
mm
Weight, with batteries
Without batteries
192 lbs / 87 Kg
139 lbs / 63 Kg
Battery
12V 36h×2
Motor
200W × 2
Charger
DC24V 4A OFF-BOARD
Front wheels
6.0“ × 2.0“ Solid / 150 × 50 mm
Drive wheels
10.2“ × 3.3 “ Solid / 260 × 85 mm
Anti-tip wheels
6.0“ × 2.0“ Solid / 150 × 50 mm
Driving system
Direct drive the mid wheel
Brake system
Electromagnetic brakes
Top speed (approximate)
5mph / 7 km/hr
Climbing angle
8°
Cruising range
12.5~ 18.5mi / 20~30 km
Turning radius
27.5” / 700 mm
Armrests
Adjustable Width, Angle,
Height
Footrest
Adjustable Height, Angle
Maxus weight
300 lbs / 136 kg
Controller
PG VR2 50A
Please note that the maximum range is based on an ambient temperature above 48
℉
, a 165 lb driver, a
brand new and fully charged battery, and a constant driving speed of 4mph with 70% battery power
discharged, driving on a flat surface.
NOTE: Specifications are subject to change without notice.
