Operation – Activeforever Image EC Mid Wheel Drive Reclining Power Wheelchair User Manual
Page 14
13
5. OPERATION
Warning
When on an incline, NEVER switch the power chair to the freewheel mode. The electromagnetic brakes
will not be applied and this may result in injury.
HOW TO ADJUST THE SEAT
▇ To adjust the seatback angle
◆
Pull up the seatback release lever.
◆
Move the seatback down or up to the desired position .
◆
Release the seatback release lever.
▇ To adjust the armrest width
◆
Loosen the knobs
◆
Slide the armrests in or out to the desired width .
◆
Tighten the knobs.
▇ To adjust the armrests angle
◆
Lift-up the armrest.
◆
Loose the jam nut.
◆
Adjust the socket screw up or down to the desired arm angle position.
◆
Tighten the jam nut
◆
To determine the same angle for the opposite armrest, count the exposed threads after the jam nut
has been tightened.
◆
If necessary, repeat the steps for the opposite armrest.
Seatback Release Lever
Jam Nut
Knob
