Activeforever Mettler Sonicator Plus 930 2-Channel Combination Therapy Device User Manual

Page 5

xx=any value from

1 to 250 Hz

Phase Duration:

125 µs internal sine wave

4–1,000 ms beat envelope

Available Amplitude

Modulation Options:

Continuous

Surge

Reciprocation

Available Channels:

All

Medium Frequency Mode

Medium Frequency (Russian)

Waveform

Waveform Type:

Burst modulated sine wave

Polarity:

None

Volts:

0–50 volts RMS, 1 Kohm load

Current:

0–50 mA RMS, 1 Kohm load

Average current at
maximum intensity
and frequency:

50 mA RMS

Maximum current
density under 2"
diameter electrode.

2.5 mA/cm²

Frequency:

2500 Hz, Burst at

10 ms on and 10 ms off

Frequency Modulation:

Phase Duration:

200 µs

Available Amplitude
Modulation Options:

Continuous

Surge

Reciprocation

Available Channels:

All
