ACR100I Reference Manual

Version 1.00

Page 16 of 20

www.acs.com

.hk

[email protected]

www.acs.com.hk

Offset

Field

Size

Value

Description

9

bClockStatus

1

value =

00h Clock running

01h Clock stopped in state L

02h Clock stopped in state H

03h Clock stopped in an unknown
state

All other values are RFU.

7.1.2.3.

RDR_to_PC_Parameters

This

message

is

sent

by

ACR100I

in

response

to

PC_to_RDR_GetParameters,

PC_to_RDR_ResetParameters and PC_to_RDR_SetParameters messages

Offset

Field

Size

Value

Description

0

bMessageType

1

82h

1

dwLength

4

Size of extra bytes of this message

5

bSlot

1

Same value as in Bulk-OUT message

6

bSeq

1

Same value as in Bulk-OUT message

7

bStatus

1

Slot status register as defined in CCID
Section 4.2.1

8

bError

1

Slot error register as defined in CCID
Section 4.2.1 and this specification
Section 5.2.8

9

bProtocolNum

1

Specifies what protocol data structure
follows.

00h = Structure for protocol T=0

01h = Structure for protocol T=1

The following values are reserved for
future use.

80h = Structure for 2-wire protocol

81h = Structure for 3-wire protocol

82h = Structure for I2C protocol

10

abProtocolDat
aStructure

Byte

array

Protocol Data Structure as summarized
in Section 5.2.3.
