7.1.1.4. PC_to_RDR_XfrBlock
Transfer data block to the ICC.
Offset Field Size Value Description
0 bMessageType 1 6Fh
1 dwLength 4 Size of abData field of this message
5 bSlot 1
Identifies the slot number for this
command
6 bSeq 1 Sequence number for command
7 bBWI 1
Used to extend the CCIDs Block
Waiting Timeout for this current
transfer. The CCID will timeout the
block after “this number multiplied by
the Block Waiting Time” has expired.
8 wLevelParameter 2 0000h RFU (TPDU exchange level)
10 abData
Byte
array
Data block sent to the CCID. Data is
sent “as is” to the ICC (TPDU
exchange level)
The response to this message is the RDR_to_PC_DataBlock message.
7.1.1.5. PC_to_RDR_GetParameters
Get slot parameters.
Offset Field Size Value Description
0 bMessageType 1 6Ch
1
DwLength
4
00000
000h
Size of extra bytes of this message
5
BSlot
1
Identifies the slot number for this
command
6 BSeq 1 Sequence number for command
7 AbRFU 3 Reserved for future use
The response to this message is the RDR_to_PC_Parameters message.
7.1.1.6. PC_to_RDR_ResetParameters
Reset slot parameters to default value.
Offset Field Size Value Description
0 bMessageType 1 6Dh
1
DwLength
4
00000
000h
Size of extra bytes of this message
5
BSlot
1
Identifies the slot number for this
command
6 BSeq 1 Sequence number for command
7 AbRFU 3 Reserved for future use
The response to this message is the RDR_to_PC_Parameters message.
