Programming the HandPunch
30
The Calibrate command displays the HandPunch’s exposure values, allowing you to verify
these values are within normal operating parameters. The standard operating parameters
are shown in Table 5
.
Table 5: Normal Operating Parameters
Parameter Normal Range
Row “r” 0 +/- 2
Column “c” 0 +/- 2
Exposure “e” 100 +/- 20
The status display command allow you to enable or disable the displaying of the following
information.
• the status values of HandPunch inputs and outputs
• the hand read score of the last user to verify on the system
When the status display is enabled, Figure 8-1 identifies each status display field value
Last Hand Read Score
Aux Out 2
Aux Out 1
* Aux Out 0
* Lock
Aux In 2
Request to Exit
Aux In 1
Door Monitor Switch
Tamper
* These status values are inactive if the
reader is in Card Reader Output Mode.
O = Circuit Open H = Output is OFF (High)
C = Circuit Closed L = Output is ON (Low)
O C O C O H L H L NN
- ENTER ID -
O C O C O H L H L NN
These Input/Output
values do not apply to
the HandPunch 2000
.
Figure 8-1: Status Display Chart
Calibrate
Status Display
