Acroprint TQ600 (software version 4.x and above) - Manual (Page 20)

14
1) Press [MENU], select “User Manage”, press [OK], select “Enroll
User”, press [OK]. Three enrollment methods are displayed, select
“Enroll FP”, press [OK]. The following screen is displayed:
2) Press [OK]. The following screen is displayed:
Note: The User ID (PIN number) is a 5 digit number. If you
input less than 5 digits the terminal pads the User ID with 0’s
in front of the User ID, i.e., if you enter 11 the User ID 00011 is
displayed on the terminal.
3) Input the User ID (range is 1 to 65534), press [OK].The following
appears:
4) You will be prompted to take (3) samples of your fingerprint. If
the test is successful three times in a row, the following appears:
New Enroll
00011-0
ESC OK (Save)
New Enroll
00011-0
Place Finger…
ESC/Exit
New Enroll
UserID 00001
ESC OK
Enroll FP
New Enroll?
ESC OK
Note: 00011-0
The dash number (-0)
indicates the first
fingerprint.
