BIOS SETUP
H/W Monitor
Apt io Setup Utilit y
Main Advance d
Chipset Boo t
PC Health Status
System Temperatur e1 + 51 C
System Temperatur e 2 + 35 C
System FAN1 Speed N /A
System FAN2 Speed 7109 RPM
VCC3V + 3.408 V
Vin0 + 0.928 V
Vin2 + 5.087 V
Vin3 + 12.232 V
VSB3V + 3.424 V
VBAT + 3.184 V
Fan1 Smart F an Control 50 C
Fan2 Smart F an Control D isabled
Secu rit y Save & Exit
→ ← Select Screen
↑↓ Select Item
Enter: Select
+-
Change Field
F1: General Help
F2: Previous Values
F3: Optimized Default
F4: Save
ESC: Exit
Temperatures/Voltages
These fields are the parameters of the hardware monitoring function
feature of the motherboard. The values are read-only values as
monitored by the system and show the PC health status.
Fan1/Fan2 Smart Fan Control
This field enables or disables the smart fan feature. At a certain
temperature, the fan starts turning. Once the temperature drops to a
certain level, it stops turning again.
