BIOS SETUP


Advanced Settings

This section allows you to configure and improve your system and
allows you to set up some system features according to your preference.

Aptio Set up Ut ility

Main

Advanced

Chip set

Bo ot

Security

Save & Exit

Legacy OpROM Support
Launch PXE OpROM

Launch Storage OpR OM

PCI Subsystem Settings

ACPI Settings

W ake up event setting

CPU Configuration

SATA Configuration

Intel IGD SWSCI OpRegion

USB Configuration

Super IO Configur ation

H/W Monitor

AMT Configur ation

Ser ial Por t Console Redir ection


→ ← Select Screen

↑↓

Select Item

Enter: Select
+- Change Field
F1: General Help
F2: Previous Values
F3: Optimized Default
F4: Save ESC: Exit

Launch PXE OpROM

Enable or Disable Boot Option for Legacy Network Devices.

Launch Storage OpROM

Enable or Disable Boot Option for Legacy Mass Storage Devices with Option
ROM.

Wake up event setting

Enable/Disable Wake up event.

Intelligent Power Sharing

Intelligent Power Sharing configuration menu.
NOTE: DTS must be enabled for Power Sharing to function.

MXM 3.0/Hybrid Graphics

Enable/Disable the MXM 3.0 support..
