8
•Type 652.03: after approx. 90 min. recharging, the red light (fig. 1 - ref. 8) begins to flash. When
reaching this charge level, the appliance is ready to operate in cordless mode up to 70 min.
•When fully recharged, the red light (fig. 1 - ref. 8) switches off.
•When the battery is fully charged, the appliance can be used up to 110 minutes without connection
to the mains.
•After a certain number of operating hours, charge duration in cordless mode may decrease
significantly.
•The maximum charge level is reached after 4 - 5 recharging procedures.
ADJUSTING THE CUTTING LENGTH
The appliance is equipped with the VARIO-CUT SYSTEM, which allows the selection of 5 different
cutting lengths (fig. 3) using the proper selector (fig. 1 - ref. 4).
CUTTING WITH GUIDE COMBS
Depending on the type of cut desired, the appliance can be used with or without a guide comb
(fig. 1 - ref. 10). Guide combs are used to achieve different cutting lengths ranging from 4 to 20 mm.
FITTING AND REMOVING THE GUIDE COMB
•Switch off the appliance.
•To fit the guide comb, slide and push it into place (fig. 4, A).
•To remove it, do the reverse operation (fig. 4, B).
CHANGING BLADES
•Switch off the appliance.
•To remove the blades, push them out of their slot from underneath (fig. 5).
•IMPORTANT: to replace the blades, set the selector (fig. 1 - ref. 4) to "3.0" (fig. 6); first insert
the rear part into the slot (fig. 6, A), then push the front to close it (fig. 6, B).
•IMPORTANT: before fitting the blade, make sure that the motor pin (fig. 8 - ref. 1) is adjusted so
that it can slot into the space on the inner side of the blade (fig. 8 - ref. 2).
CABLE REEL
The base (fig. 1 - ref. 6) has a compartment where part of the cable can be wrapped if the full length
is not required (fig. 9).
CARE AND MAINTENANCE
The cleaning and maintenance procedure must be carried out after every use.
•Switch OFF the appliance and disconnect it from the mains supply before performing any
maintenance or changing any parts.
•Never immerse the appliance in water!
•After every use, remove the guide comb then use the small brush to eliminate any hair from the
cutting head and its seat.
•Clean the outside of the appliance with a soft cloth (slightly damp if necessary). Never use solvents
or abrasive detergents!
•Remove the cutting head (fig.5) and evenly oil the blades and the seat of the motor pin which is
located on the inside (fig. 8).
•If after prolonged use, and despite regular cleaning and lubrication, the cutting ability of the
appliance appears to be diminished, the cutting head must be replaced.
DISPOSAL
The appliance must be disposed of in compliance with applicable environmental standards.
This appliance conforms to European Directives 2004/108/EC, 2006/95/EC,
2009/125/EC and Regulation (EC) No. 278/2009.
