Control:
1 = Not Applicable
X-Chip 100 & 300
System
Max. in Chain
Cabling System
Control
DMX Channels
Addressing DMX
Power requirements
Current Consumption
Light Source
Power Consumption
Weight
Housing
Source Life
Operating Temp.
Storage Temp.
Including
24Vdc / 5-Wire
50 pcs
5 pin Flat Cable (2 wires 24V + 3 wires signal)
X-Power TV or X-Chip Driver TV
X-Chip Driver IR
Controled by 3 DMX Channels
-
-
50mA
X-Chip-100 = 5 x SMD 5050
X-Chip-300 = 6 x SMD 5050
X-Chip-100 = 1,2W / X-Chip-300 =1,5W
X-Chip-100 = 11 gr / X-Chip-300 =30 gr
PCB
50.000 hours
-0 °C ~ +40 °C
-20 °C ~ +70 °C
Mounting clips and one 10 cm Link Cable
- x x x - x x x x
Version:
N = Normal
Color:
C
G
H
N
P
Q
R = WW 3200k
= CW 6000k
= RGB
= Red
= Green
= Blue
= Amber
Beam angle:
A = Open beam
LED Config:
A = 5 LEDs SMD 100 mm
B = 6 LEDs SMD 300 mm
Cover:
4 = No Cover
Housing:
3 = Gray Color
XCA
Model Number
XCA-134-AAHN
XCA-134-BAHN
Product name
X-Chip 100 SMD RGB 5-LED‘s
X-Chip 300 SMD RGB 6-LED‘s
Length
100 mm
300 mm
Beam
120º
120º
Color
RGB
RGB
Delivery including
Mounting clips and one 10 cm Link Cable
Mounting clips and one 10 cm Link Cable
100mm [3.9"] 300mm [11.8"]
82mm [3.2"]
X-Chip 300 X-Chip 100
16mm [0.6"]
16mm [0.6"]
Indoor Fixtures
www.acclaimlighting.eu
Model number
Dimensions
Projects
