Acclaim Lighting AL Panel Pro Frame User Manual
Al panel pro frame, X x x - x x x x, Indoor fixtures

www.acclaimlighting.com
AL Panel Pro Frame
Indoor Fixtures
Projects
** All rights reserved. Improvements changes to specifications, design, and all contents in this catalog may be made at any time without prior notice.
Control:
2 = DMX
System
Max. in Chain
Cabling System
Control
Pixels
Pixel Pitch
DMX Channels
Addressing DMX
Power requirements
Current Consumption
Light Source
Power Consumption
Weight
Housing
Source Life
Operating Temp.
Storage Temp.
Including
100-240Vac + DMX-1000
1 Compleet Frame
AC Power-cable + 1 DMX Cable
DMX-1000
300
40 mm
Controled by 900 DMX Channels
XB-R1 Setup Tool
24Vdc
4,8A
300 x SMD 5050
120W
300 gr / 480 gr
Metal Frame and Polycarbonate Panels
50.000 hours
-0 °C ~ +37 °C
-20 °C ~ +60 °C
1 x Frame and 1 x X-PD-150
and 12 x AL Panel Pro and link cables
Model number
- x x x - x x x x
Version:
E = 240Vac ( VDE plug )
U = 100Vac ( UL plug )
Color:
C
G
H
N
P
Q
= WW 3200k
= CW 6000k
= RGB
= Red
= Green
= Blue
Beam angle:
A = Open beam
LED Config:
A = 12x25 LEDs
Cover:
4 = No Cover
Housing:
1 = Black Color
APL
Dimensions
Model Number
APL-214-AAHE
APL-214-AAHU
Product name
AL Panel Pro Frame (VDE)
AL Panel Pro Frame (UL)
Luminous Intensity
520 cd/m²
520 cd/m²
Beam
120º
120º
Color
RGB
RGB
Delivery including
12 x AL Panel Pro and 1 x X-PD-150 (VDE)
12 x AL Panel Pro and 1 x X-PD-150 (UL)
650mm [2'-1.6"]
800mm [2'-7.5"]
500mm [1'-7.7"]
400mm [1'-3.7"]
600mm [1'-11.6"]
652mm [2'-1.7"]
730mm [2'-4.7"]
147mm [5.8"]
