SPECIFICATION
S-150-5 S-150-7.5 S-150-9 S-150-12 S-150-13.5 S-150-15 S-150-24 S-150-27 S-150-48 MODEL
DC VOLTAGE
RATED CURRENT
CURRENT RANGE
RATED POWER
OUTPUT VOLTAGE ADJ. RANGE
LINE REGULATION
LOAD REGULATION
SETUP, RISE TIME
HOLD TIME (Typ.)
VOLTAGE RANGE
FREQUENCY RANGE
EFFICIENCY (Typ.)
INPUT
INRUSH CURRENT (Typ.)
LEAKAGE CURRENT
WORKING TEMP.
WORKING HUMIDITY
STORAGE TEMP., HUMIDITY
TEMP. COEFFICIENT
VIBRATION
MTBF
DIMENSION OTHERS
NOTE
PACKING
OVER LOAD
OVER VOLTAGE
AC CURRENT (Typ.)
5V 7.5V 9V 12V 13.5V 15V 24V 27V 48V
30A 20A 16.7A 12.5A 11.2A 10A 6.5A 5.6A 3.2A
0 ~ 30A 0 ~ 20A 0 ~ 16.7A 0 ~ 12.5A 0 ~ 11.2A 0 ~ 10A 0 ~ 6.5A 0 ~ 5.6A 0 ~ 3.2A
150W 150W 150.3W 150W 151.2W 150W 156W 151.2W 153.6W
150mVp-p 150mVp-p 180mVp-p 180mVp-p 180mVp-p 180mVp-p 240mVp-p 240mVp-p 240mVp-p
4.5 ~ 5.5V 6 ~ 8.3V 8 ~ 10.4V 10.6 ~ 13.2V 12 ~ 15V 13.5 ~ 16.5V 21 ~ 28V 24 ~ 30V 43 ~ 53V
2.0% 1.0% 1.0% 1.0% 1.0% 1.0% 1.0% 1.0% 1.0%
0.5% 0.5% 0.3% 0.3% 0.3% 0.3%
0.3% 0.3% 0.3% 0.3%
0.2% 0.2% 0.2%
0.5% 0.5% 0.2% 0.2% 0.2%
100ms, 50ms at full load
28ms at full load
88 ~ 132VAC/176 ~ 264VAC selected by switch 248 ~ 370VDC
47 ~ 63Hz
78%
5.75 ~ 6.75V
80%
8.63 ~ 10.13V
80%
10.35 ~ 12.2V
82%
13.8 ~ 16.2V
83%
15.53 ~ 18.2V
84%
17.25 ~ 20.3V
85%
30 ~ 34.8V
86%
31.1 ~ 36.45V
87%
55.2 ~ 64.8V
3.2A/115VAC 1.6A/230VAC
COLD START 35A
<3.5mA / 240VAC
105 ~ 150% rated output power
Protection type : Shut down o/p voltage, re-power on to recover
Protection type : Shut down o/p voltage, re-power on to recover
-10 ~ +60 (Refer to output load derating curve)
20 ~ 90% RH non-condensing
-20 ~ +85 , 10 ~ 95% RH
0.03%/ (0 ~ 50
10 ~ 500Hz, 2G 10min./1cycle, 60min. each along X, Y, Z axes
286.7K hrs min. MIL-HDBK-217F (25 )
199*110*50mm (L*W*H)
0.8Kg; 16pcs/13.8Kg/0.95CUFT
SAFETY STANDARDS UL1012, UL60950-1, TUV EN60950-1 Approved
Compliance to EN55022 (CISPR22) Class B
HARMONIC CURRENT
EMS IMMUNITY
Compliance to EN61000-3-2,-3
Compliance to EN61000-4-2,3,4,5,6,8,11; ENV50204, EN55024, Light industry level, criteria A
150W Single Output Switching Power Supply
S - 1 5 0
s e r i e s
AC input range selectable by switch
Protections:Short circuit/Over load/Over voltage
Cooling by free air convection
100% full load burn-in test
Fixed switching frequency at 25KHz
Features :
ENVIRONMENT
SAFETY &
EMC
(Note 4)
PROTECTION
EMI CONDUCTION & RADIATION
WITHSTAND VOLTAGE
ISOLATION RESISTANCE
I/P-O/P:3KVAC I/P-FG:1.5KVAC O/P-FG:0.5KVAC
I/P-O/P, I/P-FG, O/P-FG:100M Ohms/500VDC
RIPPLE & NOISE (max.) Note.2
VOLTAGE TOLERANCE Note.3
1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25 of ambient temperature.
2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.
3. Tolerance : includes set up tolerance, line regulation and load regulation.
4. The power supply is considered a component which will be installed into a final equipment. The final equipment must be re-confirmed that it still meets
EMC directives.
