AL Puzzle Image
Control:
2 = DMX
System
Max. in Chain
Cabling System
Control
Pixels
Pixel Pitch
DMX Channels
Addressing DMX
Power requirements
Current Consumption
Light Source
Power Consumption
Weight
Housing
Source Life
Operating Temp.
Storage Temp.
Including
24Vdc + DMX
10 pcs
2-wire DC Power-cable + 1 DMX Cable
Direct DMX-512 or DMX-1000
16
63,5 mm / 2,5“
Controled by 48 DMX Channels
Auto DMX Addressing
24Vdc
250mA
16 x SMD 5050
6W Master
120 gr
PCB Type
50.000 hours
-0 °C ~ +40 °C
-20 °C ~ +70 °C
Mounting clip & 7 cm link cable
- x x x - x x x x
Version:
N = Normal
Color:
C
G
H
N
P
Q = WW 3200k
= CW 6000k
= RGB
= Red
= Green
= Blue
Beam angle:
A = Open beam
LED Config:
A = 16 LEDs ( 16-Pixel )
Cover:
4 = No Cover
Housing:
1 = Black Color
2 = White Color
APC
Model Number
APC-214-AAHN
Product name
AL Puzzle Image RGB (Black PCB)
Luminous Intensity
62,39 cd
Beam
113º
Color
RGB
Delivery including
Mounting clip & link cable
203mm [8.0 in]
203mm [8.0 in]
62mm [2.4 in]
62mm [2.4 in]
5mm [0.2 in]
111mm [4.4 in]
77mm [3.0 in]
15mm [0.6 in]
Mounting clip
46mm [1.8 in]
Indoor Fixtures
