Acclaim Lighting AL Pixel 1 - Manual (Page 2)

AL Pixel 1 (IP65)
Control:
2 = DMX
System
Max. in Chain
Cabling System
Control
Pixels
Pixel Pitch
DMX Channels
Addressing DMX
Power requirements
Current Consumption
Light Source
Total Lumens
Power Consumption
Weight
Housing
Source Life
Operating Temp.
Storage Temp.
Including
9Vdc + DMX
1 string
4-wire cable + 4-pin connector
AL Pixel Driver 9V (DMX-512 or DMX-1000)
50 pixels
Max. 350mm
150 channels
Auto DMX Addressing
9Vdc
55mA per pixel / 2,8A per 50 pixels
50 x SMD 5050
3,6 lm per pixel
0,5W per pixel / 25W per 50 pixels
2,50 kg
Polycarbonate with UV stablizer
50.000 hours
-20 °C ~ +40 °C
-20 °C ~ +70 °C
Feet Cable 5 meter
- x x x - x x x x
Version:
N = Normal
Color:
C
G
H = WW 3200k
= CW 6000k
= RGB
Beam angle:
A = Open beam
LED Config:
A = 50 LEDs 10cm
B = 50 LEDs 15cm
C = 50 LEDs 30cm
D = 50 LEDs 35cm
Cover:
1 = Clear
Housing:
1 = Black Color
2 = White Color
9 = Special Color
APE
Model Number
APE-221-DAHN
APE-221-CAHN
Product name
AL Pixel 1 (string 50 dots & 35cm Pitch)
AL Pixel 1 (string 50 dots & 30cm Pitch)
Total Lumens
3,6 lm Per pixel
3,6 lm Per pixel
Beam
120º
120º
Color
RGB
RGB
Delivery including
Feet Cable 5 meter
Feet Cable 5 meter
Control
AL Pixel Driver (9V + DMX)
AL Pixel Driver (9V + DMX)
Outdoor Fixtures
www.acclaimlighting.eu
Model number
Dimensions
** All rights reserved. Improvements changes to specifications, design, and all contents in this catalog may be made at any time without prior notice.
ACCLAIM
LIGHTING
24mm [0.9 in] 19mm [0.7 in]
14mm [0.5 in]
GND
DMX-
DMX+
9V
GND
DMX-
DMX+
9V
9V DC and DMX
standard 5 m (16.4 ft)
pixel pitch
max. 300 mm (1 ft)
max. 50 nodes in a chain
AL Pixel1
DMX 512 in
DMX 512 out
(Auto addressing)
100V/240V AC in
AL Pixel 1 Driver
main control panel
Wiring diagram
