Acclaim Lighting AL Stick ND IP65 - Manual (Page 2)

+24V GND
l D M X l D- GND
D+
max.15 m (50 ft) total fixture length in a chain
5 pin WP first cable
standard 2 m (6.56 ft)
optional
5 pin WP link cable
AL Stick ND IP65
24V DC in
NC
Control:
1 = Not Applicable
AL Stick ND IP65 500/1000 (SC)
System
Max. in Chain
Cabling System
Control
DMX Channels
Addressing DMX
Power requirements
Current Consumption
Light Source
Power Consumption
Weight
Housing
Listing
Source Life
Operating Temp.
Storage Temp.
Including
24Vdc PWM (2-wire)
1 pc
2-wire DC cable
DC Power or Any 24Vdc PWM Dimmer
AL Driver 8 RGBW 24V or AL Dimmer 1 Pro
Controled by 1 DMX Channel
-
24Vdc
200mA / 400mA
24 / 48 x SMD 5050
5W / 10W
300 gr / 600 gr
Aluminum extrusion
CE Certified
50.000 hours
-20 °C ~ +40 °C
-20 °C ~ +70 °C
Input cable with 5-pin WP male conn.
Output cable with 5-pin WP female conn.
- x x x - x x x x
Version:
N = Normal
Color:
C
E
G
N
P
Q
R = WW 3200k
= NW 4000k
= CW 6000k
= Red
= Green
= Blue
= Amber
Beam angle:
A = Open beam
LED Config:
A = 24 LEDs SMD (500 mm)
B = 48 LEDs SMD (1000 mm)
Cover:
1 = Clear
Housing:
4 = Aluminum
ASD
Model Number
ASD-141-AACN
ASD-141-BACN
ASD-141-AAGN
ASD-141-BAGN
Product name
AL Stick ND IP65 500 WW
AL Stick ND IP65 1000 WW
AL Stick ND IP65 500 CW
AL Stick ND IP65 1000 CW
Length
500 mm
1000 mm
500 mm
1000 mm
Beam
120º
120º
120º
120º
Color
White 3200k
White 3200k
White 6000k
White 6000k
Delivery including
Fixed input and output Cable
Fixed input and output Cable
Fixed input and output Cable
Fixed input and output Cable
54mm [2.1 in]
1000mm [39.4 in]
46mm [1.8 in]
500mm [19.7 in]
28mm [1.1 in]
Outdoor Fixtures
www.acclaimlighting.eu
Model number
Dimensions
Wiring diagram
