AL Ball MK-l DMX (IP65)

System

Max. in Chain
Cabling System

Control
DMX Channels
Addressing DMX
Power requirements
Current Consumption
Light Source
Power Consumption
Weight
Housing

Listing
Source Life
Operating Temp.
Storage Temp.
Including

24Vdc + DMX

(Backside cable entree)

20 pcs
5-Pin IP67 Waterproof Conn. (Power + DMX)
( cable entry Backside )
Direct DMX-512, Manual, Stand Alone
3 DMX Channels
XB-R1 Setup Tool
24Vdc
105mA
12 x SMD 5050
2,5W
300 gr
Aluminum alloy construction with
Polycarbonate and UV Stabilizer
CE Certified
50.000 hours
-20 °C ~ +40 °C
-20 °C ~ +70 °C
Input cable with 1 pc 5-pin WP male conn.

Control:

2 = DMX

- x x x - x x x x

Version:

N = Normal

Color:

C
E
G
H
N
P
Q

= WW 3200k
= NW 4000k
= CW 6000k
= RGB
= Red
= Green
= Blue

Beam angle:

A = Open beam 108º

LED Config:

A = 12 LEDs

Cover:

1 = Clear
2 = Frosted

Housing:

1 = Black Color
4 = Aluminum Color

ABD

93mm [3.7 in]

73mm [2.9 in]

56mm [2.2 in]

77mm [3.0 in]

53mm [2.1 in]

Outdoor Fixtures

www.acclaimlighting.eu

Model number

Dimensions

Projects

** All rights reserved. Improvements changes to specifications, design, and all contents in this catalog may be made at any time without prior notice.

ACCLAIM

LIGHTING
