Acclaim Lighting X-Chip ll - Manual (Page 2)

Control:
4 = Master DMX
5 = Slave
X-Chip ll
System
Max. in Chain
Cabling System
Control
DMX Channels
Addressing DMX
Power requirements
Current Consumption
Light Source
Power Consumption
Weight
Housing
Listing
Source Life
Operating Temp.
Storage Temp.
Including
24Vdc + DMX
1 pc Masters with 20 pcs Slave
or 32 pcs Masters
2-wire DC Power-cable + 1 DMX Cable
Direct DMX-512, Manual, Stand Alone
Controled by 3 DMX Channels
XB-R1 Setup Tool
24Vdc
70mA Master / 50mA Slave
6 x SMD 5050
1,7W Master / 1,2W Slave
30 gr Master / 10,8 gr Slave
PCB
CE Certified
50.000 hours
-0 °C ~ +40 °C
-20 °C ~ +70 °C
Mounting clips and 1 x 10 cm Link Cable
- x x x - x x x x
Version:
N = Normal
Color:
H = RGB
Beam angle:
A = Open beam
LED Config:
A = 6 SMD LEDs
Cover:
4 = No Cover
Housing:
3 = Gray Color
XCD
Model Number
XCD-434-AAHN
XCD-534-AAHN
Product name
X-Chip ll -125 Master
X-Chip ll -125 Slave
Length
12,5 cm
12,5 cm
Beam
120º
120º
Color
RGB
RGB
Delivery including
Mounting clips and 1 x 10 cm Link Cable
Mounting clips and 1 x 10 cm Link Cable
125mm [4.9 in] 22mm [0.9 in]
26mm [1.0 in]
82mm [3.2 in]
23mm [0.9 in]
Master
Master
Indoor Fixtures
www.acclaimlighting.eu
Model number
Dimensions
Projects
** All rights reserved. Improvements changes to specifications, design, and all contents in this catalog may be made at any time without prior notice.
