Acclaim Lighting AL Stick ND IP68 - Manual (Page 2)

Control:
1 = Not Applicable
AL Stick ND IP68 500/1000 (SC)
System
Max. in Chain
Cabling System
Control
DMX Channels
Addressing DMX
Power requirements
Current Consumption
Light Source
Power Consumption
Weight
Housing
Listing
Source Life
Operating Temp.
Storage Temp.
Including
24Vdc PWM (2-wire)
1 pc
2-wire DC cable + ground
DC Power or Any 24Vdc PWM Dimmer
AL Driver 8 RGBW 24V or AL Dimmer 1 Pro
Controled by 1 DMX Channel
-
24Vdc
200mA / 400mA
24 / 48 x SMD 5050
5W / 10W
300 gr / 600 gr
Aluminum extrusion in special anodize proces
CE Certified
50.000 hours
-20 °C ~ +40 °C
-20 °C ~ +70 °C
18 m cable with terminal connector
- x x x - x x x x
Version:
N = Normal
Color:
C
E
G
N
P
Q
R = WW 3200k
= NW 4000k
= CW 6000k
= Red
= Green
= Blue
= Amber
Beam angle:
A = Open beam
LED Config:
A = 24 LEDs SMD (500 mm)
B = 48 LEDs SMD (1000 mm)
Cover:
1 = Clear
Housing:
4 = Aluminum
ASE
Model Number
ASE-141-BACN
ASE-141-BAGN
Product name
AL Stick ND IP68 1000 WW
AL Stick ND IP68 1000 CW
Length
1000 mm
1000 mm
Beam
120º
120º
Color
White 3200k
White 6000k
Delivery including
18 m cable with terminal connector
18 m cable with terminal connector
54mm [2.1 in]
1000mm [39.4 in]
46mm [1.8 in]
500mm [19.7 in]
28mm [1.1 in]
Outdoor Fixtures
www.acclaimlighting.eu
Model number
Dimensions
** All rights reserved. Improvements changes to specifications, design, and all contents in this catalog may be made at any time without prior notice.
ACCLAIM
LIGHTING
+24V GND
ART-SCC
or any other
DMX-512 controller
100V/240V AC
3 core cable
standard 18m (60 ft)
AL Stick ND IP68 SC
24V DC +
24V DC -
GND
Wiring diagram
