Control:
1 = Not Applicable
AL Strip Mini RGB (IP65)
System
Max. in Chain
Cabling System
Control
DMX Channels
Addressing DMX
Power requirements
Current Consumption
Light Source
Power Consumption
Weight
Housing
Listing
Source Life
Operating Temp.
Storage Temp.
Including
24Vdc PWM (4-wire)
6 pcs
4-wire DC cable
AL Driver 8 RGBW 24V or X-Dimmer 3 Pro
Controled by 3 DMX Channel
-
24Vdc
200mA
24 x SMD 5050
4,8W
90 gr
Aluminum extrusion in anodize process
CE Certified
50.000 hours
-20 °C ~ +40 °C
-20 °C ~ +70 °C
2 pcs Mounting clips & open end
fixed Cables
- x x x - x x x x
Version:
N = Normal
Color:
H = RGB
Beam angle:
A = Open beam
LED Config:
A = 24 LEDs 500 mm
Cover:
1 = Clear
Housing:
4 = Aluminum Color
ASJ
Model Number
ASJ-141-AAHN
Product name
AL Strip Mini RGB 500 IP65
Length
500 mm
Beam
120º
Color
RGB
Delivery including
2 pcs Mounting clips
500mm [19.7 in]
463mm [18.2 in]
7mm [0.3 in]
13mm [0.5 in]
Outdoor Fixtures
www.acclaimlighting.eu
Model number
Dimensions
** All rights reserved. Improvements changes to specifications, design, and all contents in this catalog may be made at any time without prior notice.
ACCLAIM
LIGHTING
10 9 8 7 6 5 4 3 2 1
GND
Data -
Data+
GND
Data -
Data+
+12-24V
GND
Blue
Green
Red
+12-24V DMX IN
DMX OUT
DC IN 6A Max X-DIMMER-3 PRO
DMX ADDRESS SETTING
On
OUTPUT
6A max.
max.6pcs AL Strip Mini RGB in a chain
AL Strip Mini RGB
4 core cable
standard 250mm (0.82 ft)
4 core cable
standard 250mm (0.82 ft)
junction box
X- Dimmer-3 Pro
DMX IN
DMX OUT
24V DC
Wiring diagram
