Cat Walk Panel (touch controle)
Control:
2 = DMX
System
Max. in Chain
Cabling System
Control
Pixels
Pixel Pitch
DMX Channels
Addressing DMX
Power requirements
Current Consumption
Light Source
Power Consumption
Weight
Housing
Source Life
Operating Temp.
Storage Temp.
Inductive Distance
Including
24Vdc + DMX
6 pcs using DMX-512 / 11 pcs using DMX-1000
2-wire DC Power-cable + 1 DMX Cable
Direct DMX-512 or DMX-1000
25
40 mm
Controled by 75 DMX Channels
Auto DMX Addressing
24Vdc
450mA
25 x SMD 5050
10,8W
225 gr
PCB Type
50.000 hours
-10 °C ~ +50 °C
-20 °C ~ +70 °C
20 mm Max.
Mounting tape +
Link Cable 6-pin Terminal 90 mm
- x x x - x x x x
Version:
N = Normal
Color:
H = RGB
Beam angle:
A = Open beam
LED Config:
A = 25 LEDs
Cover:
4 = No Cover
Housing:
2 = White Color
CWA
Model Number
CWA-224-AAHN
Product name
Catwalk Panel RGB
Luminous Intensity
915 cd/m²
Beam
120º
Color
RGB
Delivery including
Mounting tape + Link Cable
Indoor Fixtures
www.acclaimlighting.eu
Model number
Dimensions
Projects
** All rights reserved. Improvements changes to specifications, design, and all contents in this catalog may be made at any time without prior notice.
ACCLAIM
LIGHTING
192mm [7.6 in]
192mm [7.6 in]
8mm [0.3 in]
40mm [1.6 in]
