Control:
1 = Not Applicable
X-Chip 6100
System
Max. in Chain
Cabling System
Control
DMX Channels
Addressing DMX
Power requirements
Current Consumption
Light Source
Power Consumption
Weight
Housing
Source Life
Operating Temp.
Storage Temp.
Including
24Vdc PWM (4-wire)
40 pcs
4-wire DC cable
AL Driver 8 RGBW 24V or X-Dimmer 3 Pro
Controled by 3 DMX Channels
-
24Vdc
50mA
15 x SMD 3528
1,2W
15 gr
PCB
50.000 hours
-0 °C ~ +40 °C
-20 °C ~ +70 °C
Mounting clips and one 10 cm Link Cable
- x x x - x x x x
Version:
N = Normal
Color:
A
B
C
D
E
F
G = CW-B-CW
= WW-A-B
= CW-WW-CW
= WW-CW-WW
= WW-A-WW
= CW-A-CW
= CW-A-WW
Beam angle:
A = Open beam
LED Config:
A = 15 LEDs SMD 100 mm
Cover:
4 = No Cover
Housing:
3 = Gray Color
XCC
Model Number
XCC-134-AADN
XCC-134-AACN
XCC-134-AAEN
Product name
X-Chip 6100 WW-CW-WW SMD-3528
X-Chip 6100 CW-WW-CW SMD-3528
X-Chip 6100 WW-A-WW SMD-3528
Length
100 mm
100 mm
100 mm
Beam
120º
120º
120º
Color
2 x 3200K & 1 x 6000k
1 x 3200K & 2 x 6000k
2 x 3200K & 1 x Amber
Delivery including
Mounting clips and one 10 cm Link Cable
Mounting clips and one 10 cm Link Cable
Mounting clips and one 10 cm Link Cable
82mm [3.2 in]
16mm [0.6 in] 16mm [0.6 in]
100mm [3.9 in]
Outdoor Fixtures
www.acclaimlighting.eu
Model number
Dimensions
Projects
** All rights reserved. Improvements changes to specifications, design, and all contents in this catalog may be made at any time without prior notice.
