Control:
1 = Not Applicable
Rebel Chip
System
Max. in Chain
Cabling System
Control
DMX Channels
Addressing DMX
Power requirements
LED Current
Light Source
Power Consumption
Weight
Housing
Listing
Source Life
Operating Temp.
Storage Temp.
Including
Constant Current (5-Wire)
12 pcs
5-wire DC
Rebel Chip Driver
Controled by 3 DMX Channels
-
-
350mA Max
3 x Rebel LED (1W)
5W
50 gr
Aluminum extrusion and Polycarbonate
with UV Stabilizer
CE, cETLus
50.000 hours at 70% lumen maintenance
-0 °C ~ +40 °C
-20 °C ~ +70 °C
30 cm link cable witch 5-pin terminal conn.
- x x x - x x x x
Version:
N = Normal
Color:
A
C
E
G
H
M
N
P
Q
R = WW 2700k
= WW 3200k
= NW 4000k
= CW 6000k
= RGB
= WW-CW-WW
= Red
= Green
= Blue
= Amber
Beam angle:
A
U = Open beam
= 20 x 40°
LED Config:
A = 3 LEDs
Cover:
1 = Clear
Housing:
4 = Aluminum Color
RCA
120mm [4.7in]
24mm [1.0in] 22mm [0.9in]
120mm [4.7in]
24mm [1.0in] 25mm [1.0in]
120mm [4.7in]
120mm [4.7in]
Indoor Fixtures
Wiring diagram
www.acclaimlighting.eu
Model number
Dimensions
** All rights reserved. Improvements changes to specifications, design, and all contents in this catalog may be made at any time without prior notice.
