Acclaim Lighting AL Bar AC DMX (IP65) - Manual (Page 2)

www.acclaimlighting.eu
Projects
Dimensions
Model number
Control:
2 = DMX
AL Bar AC DMX (IP65)
System
Max in Chain (DMX-512)
Max in Chain (DMX-1000)
Cabling System
Control
Pixels
DMX Channels
Total Lumens
Candela
Addressing DMX
Power requirements
Current Consumption
Light Source
Power Consumption
Weight
Housing
Listing
Source Life
Operating Temp.
Storage Temp.
Including
100-240Vac + DMX
20 Mtr @ 100Vac and 20 Mtr @ 240Vac
36 Mtr @ 100Vac and 72 Mtr @ 240Vac
8-Pin IP67 Waterproof Conn. (Power + DMX)
Direct DMX-512 or DMX-1000
5 pixels / 10 pixels
15 channels / 30 channels
52,3 lm / 104,6 lm
12,29 Cd / 24,57 Cd
Auto DMX Addressing
100-240Vac, 277Vac
80mA
30 / 60 pcs SMD 5050
10W / 30W
2 kg / 4 kg
Alu extrusion case, PC cover (UV stabilizer)
CE, cETLus
50.000 h under normal operating conditions
-20 °C ~ +40 °C
-20 °C ~ +70 °C
Short Link Cable (fixed attached)
- x x x - x x x x
Version:
N = 100-277Vac
Color:
C = WW 3200k
E = CW 6000k
G = NW 4000k
H = RGB
N = Red
P = Green
Q = Blue
Beam angle:
A = Open beam
LED Config:
A = 30 LEDs 60cm (5 pixels)
B = 60 LEDs 120cm (10 pixels)
Cover:
2 = Frosted
Housing:
3 = Gray Color
ABA
Model Number
ABA-232-AAHN
ABA-232-BAHN
Product name
AL Bar AC 600 RGB
AL Bar AC 1200 RGB
Luminous Intensity
52,3 lm
104,6 lm
Beam
120º
120º
Color
RGB
RGB
Delivery including
100-277Vac + DMX
100-277Vac + DMX
Outdoor Fixtures
** All rights reserved. Improvements changes to specifications, design, and all contents in this catalog may be made at any time without prior notice.
ACCLAIM
LIGHTING
1200mm [47.2 in]
67mm [2.7 in]
96mm [3.8 in]
1199mm [47.2 in]
