Acclaim Lighting AL Stick IP65 RGB - Manual (Page 2)

Control:
2 = DMX
AL Stick IP65 500/1000 RGB
System
Max. in Chain
Cabling System
Control
DMX Chan.
L=500mm
DMX Chan. L=1000mm
Addressing DMX
Power requirements
Current Consumption
Light Source
Power Consumption
Weight
Housing
Source Life
Operating Temp.
Storage Temp.
Including
24Vdc + DMX
8 m
5-Pin IP67 Waterproof Conn. (Power + DMX)
Direct DMX-512, Manual, Stand Alone
Min. 3 DMX Chan. Max. 12 DMX Chan. (4-pixels)
Min. 3 DMX Chan. Max. 24 DMX Chan. (8-pixels)
XB-R1 Setup Tool
24Vdc
230mA / 430mA
24 / 48 x SMD 5050
5,5W / 10,5W
300 gr / 480 gr
Aluminum extrusion
50.000 hours
-20 °C ~ +40 °C
-20 °C ~ +70 °C
Input cable with 5-pin WP male conn.
Output cable with 5-pin WP female conn.
- x x x - x x x x
Version:
N = Normal
Color:
H = RGB
Beam angle:
A= Open beam
LED Config:
A = 24 LEDs SMD (500 mm)
B = 48 LEDs SMD (1000 mm)
Cover:
1 = Clear
Housing:
4 = Aluminum
ASF
Model Number
ASF-241-AAHN
ASF-241-BAHN
Product name
AL Stick IP65 500 RGB
AL Stick IP65 1000 RGB
Length
500 mm
1000 mm
Beam
120º
120º
Color
RGB
RGB
Delivery including
Fixed input and output Cable
Fixed input and output Cable
54mm [2.1 in]
1000mm [39.4 in]
46mm [1.8 in]
500mm [19.7 in]
28mm [1.1 in]
Outdoor Fixtures
www.acclaimlighting.eu
Model number
Dimensions
Projects
** All rights reserved. Improvements changes to specifications, design, and all contents in this catalog may be made at any time without prior notice.
