When you turn the wiper switch to
the ‘‘OFF’’ position, the wiper will
return to its parked position.
OFF Turn Signal
OFF
Parking and interior lights
AUTO
Headlights on
High Beams
Flash high beams
Rotate the switch
counterclockwise also to spray the
window washer and turn the wiper
on.
When you shift the transmission to
the reverse position with the front
windshield wiper activated, the rear
wiper operates automatically even if
the rear wiper switch is off.
The rear window washer uses the
same fluid reservoir as the wind-
shield washer.
Hold past ON to activate the rear
window wiper a few times and to
spray the rear window washer.
The wiper operates every 7
seconds after completing two
sweeps.
Rotate the switch clockwise to
turn the rear window wiper ON.
If equipped
4.
3.
1.
2.
1.
2.
3.
4.
5.
6.
7.
:
Rear Window Wiper and Washer Turn Signals and Headlights
Windshield Wipers and Washers, Turn Signals and Headlights
76
EX-L model is shown.
