11
The operating controls
SKM 2020 D radio microphone
³
Sound inlet basket
·
Body of radio microphone
»
Battery compartment
(not visible from outside)
¿
Display section
´
LC display
²
Turnable protective cap for operating controls
(shown removed);
the following operating controls become acces-
sible in turn by turning the protective cap:
¶ SET
button
º ̄ button
¾ ̆ button
µ
Operation / battery status indicator,
red LED (
ON / LOW BATT )
¸ ON
/ OFF button
with ESC function (cancel) in
the operating menu
¹ MUTE
switch
ቢ
Channel display
ባ
Lock mode icon
ቤ
4-step battery status indication
ብ
7-step audio level display “AF”
³ · » ¿ ´ ²
¶
²
º ¾
µ
¸
¹
CH 03
ባ ቢ
ብ ቤ
