Setting (fig. 2)
1. Remove the cover from the device by unscrewing the six screws
2. Use the turnbuckle to tighten the cable until it is aligned with the index opposite point
3. Rotate the cam to position it where required, based on the maximum allowable temperature difference in
operation (fig. 3)
4. Use the rigging screw to readjust the position of the index
5. Arm the device by pressing the switch : you should hear a "click"
6. Actuate the device by pulling the cable
7. Repeat steps 5 and 6 once more
8. Check the position of the index and repeat steps 4 to 8 if required
9. Mount the cover onto the device using the six screws (tightening torque = 1.5±0.1 Nm / 1.1±0.07 lb.ft)
or move to the wiring stage
NOTE: The diagrams show a "right-anchored" device: reverse the diagrams for a "left-anchored" device
.
NOTE: You can compensate for expansion/contraction of the cable by adjusting the configuration to take
account of temperature variations:
• Fig.4a: anticipation of a fall in temperature,
• Fig.4b: anticipation of a rise in temperature.
RISK OF ELECTRIC SHOCK, EXPLOSION OR ARC FLASH
• Switch off the power supply of the device
• Use appropriate personal protective equipment (PPE) and follow the relevant working instructions for
electrical environments. See NFPA 70E.
• Always use an appropriate electrical measuring device to confirm that the entire installation is powered
down.
Failure to follow these instructions will result in death or serious injury.
RISK OF UNINTENDED EQUIPMENT OPERATION
Check that the device, cable and accessories are securely mounted in place
Failure to follow these instructions will result in death or serious injury.
RISK OF FALL, COLLISION OR CRUSHING
• Do not pull on the cable while adjusting the cam
• Configure the device on the basis of the ambient temperature
Failure to follow these instructions can result in death, serious injury, or equipment damage.
