3-7. Mirror
Function name:
Mirror Configuration
Function description:
Mirror Configuration is to monitor the traffic of the network. For example, we
assume that Port A and Port B are “Mirror To” Port and “Mirror” Port
respectively, thus, the traffic passed by Port B will be copied to Port A for
monitoring.
Note:
When configur ing the mirror function, you should avoid setting a port to be a
sniffer port and aggregated port at the same time. It will cause something
wrong.
Parameter description:
Enable Mirror:
Used for the activation or de-activation of Port Mirror function. Default is
disable.
Monitored Port:
Set up the ports for being monitored. Valid port is Port 1~26 and more
than one port is allowed to be chosen at one time.
Monitoring Port:
Set up the port for monitoring. Valid port is Port 1~26.
Not Mirrored:
Choose the ports that will not be mirrored.
