Settings – QoS Setup.
QoS Feature Enable QoS – If set to Enable, it activates the QoS function.
• Queuing Method – Management method selection for packets queue.
Incorporates” Priority Queuing” - the first queuing variation to be widely
implemented.
IP TOS (Type
of Service)
Features • Process TOS Field – An 8 bit field in the IP packet header designed to
contain values indicating how each packet should be handled in the network.
If you choose "enable", it will enable this function to process IP TOS fields.
• Overwrite Policy Priority – Choose “Yes” to allow the IP TOS field priority to
overwrite the priority defined in Policy Configuration.
QoS Policy
When you use QoS, you must define some policies to enable selected packets to have higher pass-
through priority
.
Figure 7-2: QoS Policy
Page 65
