Edimax Technology ER-1088 - Manual (Page 28)

Advanced PPPoE
The Advanced PPPoE screen is required in order to use multiple PPPoE sessions on the same WAN
port.
It can also be used to manually connect or disconnect a PPPoE session.
Figure 3-3: Advanced PPPoE
Settings – Advanced PPPoE
Select WAN Port
& Session WAN Port – Selected WAN port only using PPPoE connection
PPPoE Session – ISPs can usually provide multiple floating real IPs for
PPPoE. Each WAN port can have up to eight (8) PPPoE sessions, each with
a different IP address if your WAN port is using PPPoE connectivity.
PPPoE Session MTU – The Maximum Transfer Unit for PPPoE packet data.
Leave it as default unless the ISP provides a different PPPoE packet data
size. The default MTU value is 1492 bytes.
WAN IP Account • User Name – Enter the PPPoE user name assigned by your ISP.
• Password – Enter the PPPoE password assigned by your ISP.
• Verify Password – Re-enter the PPPoE password assigned by your ISP.
Page 24
