EXTEnSiOn CORDS
Use completely unrolled and safe extension cords with a capacity
of 5 Amps.
aSSEMBLY
! WARNING
aLwaYS TURn Off THE TOOL BEfORE
CHanGinG aCCESSORiES, CHanGinG
COLLETS, OR SERViCinG THE TOOL anD REMOVE BaTTERY
PaCK.
GEnERaL
The Moto-Saw is a compact and very easy to use 2-in-1 scroll
saw. It can be used either in stationary mode, when the tool is
docked in its base or in handheld mode. This tool is intended to
perform precise straight and curved cuts in different materials
including soft wood, hard wood, composite boards, laminate,
PVC or soft sheet metal using the applicable accessories
recommended by Dremel.
PICTURE 1
A. Hold-Down Foot Release Button
B. Hold-Down Foot
C. Fence Lock Lever
D. Guide Rail
E. Base
F. Vacuum-Cleaner Connection
G. On/Off Switch
H. Speed Dial Switch
I. Securing Clamps
J. Permanent Fixing Hole
K. Quick Release Button
L. Moto-Saw
M. Accessory Quick Change Lever
inSTaLLinG anD REMOVinG aCCESSORiES
! WARNING
DiSCOnnECT THE PLUG fROM THE
POwER SOURCE BEfORE MaKinG anY
aSSEMBLY, aDJUSTMEnTS OR CHanGinG aCCESSORiES. Such
preventive safety measures reduce the risk of starting the tool
accidentally.
PICTURE 2-6
Please refer to pictures 2 to 6 for instructions about installing and
removing accessories.
DUST EXTRaCTiOn
Your tool is equipped with a dust port for dust extraction. To use
this feature attach a vacuum hose into the dust port.
PICTURE 1
EDGE GUiDE
The edge guide can be used in either of the guide rails.
This attachment can be used as a push stick or as an edge
guide/fence. When used as a push stick, there is no need to lock
it in the rails with the fence lock lever.
The guide can be used in different angles. To adjust the angle
loosen the wing screw on the guide and rotate the head into the
desired position.
The edge guide can be locked in place turning the fence lock
lever. Actuating this will prevent the guide sliding in the rail.
PICTURE 10-12
USE
GETTinG STaRTED
Thank you for purchasing the Dremel Moto-Saw. The Moto-Saw is
a compact and very easy to use 2-in-1 scroll saw. It can be used
either in stationary mode, when the tool is docked in its base or in
hand-held mode. This tool is intended to perform precise straight
and curved cuts in different materials including soft wood, hard
wood, composite boards, laminate, PVC or soft sheet metal using
the applicable accessories recommended by Dremel.
Using the Moto-Saw in stationary mode gives you the freedom to
cut different materials with both hands holding your work piece.
In this mode you can complete different hobby or wood working
projects precise and easily.
Using the Moto-Saw in hand-held mode is advisory when the work
piece is too big or fixed and therefore cannot be put onto the
base. Typical hand-held operation includes coping work or cutting
smaller pieces of materials. In hand-held mode the Moto-Saw
functions as a motorised coping/fret saw.
STaTiOnaRY MODE
1. Make sure the base is securely attached to a flat work
surface with the help of the clamps provided.
The base can be permanently secured to a work bench with
regular screws through the 2 holes located on the top of the
base. PICTURE 1
2. DO NOT sit or lean on the base. The base is meant to
support the materials being cut.
3. Once the base is secured, dock the Moto-Saw in it: first
feed the cable through the base’s hole and then simply click
the unit into the base. The Moto-Saw is securely docked,
when the hand-held unit and the stationary base are flush.
PICTURE 2-4
4. Only use the Dremel Moto-Saw in the base. Other electric
power tools are not intended to be used with the base.
5. For a clean work environment and for better line of sight,
attach a vacuum cleaner to the dust port.
6. Once your saw blade is inserted as per the user guide, the
tool is ready for operation. PICTURE 5-9
7. Start the tool and let the tool come to the right speed before
contacting the work piece. DO NOT turn the switch “ON” and
“OFF” while the tool is under load.
8. Press down the Hold-Down Foot onto your work piece to
prevent it from bouncing. To minimise vibration hold your work
piece with two hands close to the saw blade.
! WARNING
REfER TO THE PERSOnaL SafETY
CHaPTER in THiS ManUaL.
