Installation Guide

CCR3 Controller

DEN-SMT/SI

VI.D3.A2.02

Heating Solutions

1. Product description

The CCR3 Controller is a controller used to control

return temperature in one pipe heating systems

with functions such as temperature registration

and monitoring riser temperature. The controller

is connected to thermo actuators type TWA-Z (NO)

and remote temperature sensors PT1000, type

ESMC installed on each riser.

2. technical data: CCR3 Controller

3. Installation

For easy access the CCR3 Controller is installed in the

technical box on DIN rail 35 mm. Box with DIN rail

should be mounted in the wall (sub-station or boiler

room) as close as possible to the heat source. DIN rail

and box are not included. It is recommended to install

the standard 24 VAC transformer in the same box as

CCR3 (not supplied).

4. Switching the control on

Before switching the controller on for the first time,

disconnect all cables and connect a 24 VAC source

to the disconnected power plug. Use a voltmeter

to measure the voltage on the power cable plug

before it is connected to the controller.

If the voltage is correct:

1. Read the instructions before you operate the

controller

2. Disconnect all cables

3. Connect the power to the transformer (not

connected to CCR3 ”one”)

4. Turn the power to the transformer on

5. Verified currency – 24 V

6. Connect the cable from the transformer to the

CCR3 Controller input

The controller should display its name and the

software version – CONTROLLER START MENU –

display according to point 5.

Before any plugs are connected to the controllers,

input and output connectors:

1. Set all parameters on the controller

2. Make sure that there is no external voltage on the

temperature sensor plugs

3. Make sure that the voltage on the relay contacts

is not too high (max. 24 VAC)

The transformer power depends on numbers of

actuators (number of risers in heating installation).

For standard application (16 actuators-16 risers)

30 W transformer is recommended, (for 32

actuators-32 risers) 60 W recommended.

Do not install (and remove) SD card when the CCR3

is connected to the current. It must be turned off (risk

of losing data).

Temperature sensor (S0, S1-S16)

Pt1000, S0

type ESMC/ESM11, S1-S16 – type ESMC

Temperature range (registration)

–20 °C … +120 °C

Measuring accuracy

+/- 0,5 K

Inputs: B1 and B2

Free contact (5 V 1 mA)

Number of control valves (risers)

16 basic, additional 16 with parallel connection ( 32 all together ,

one temperature sensor is used as common for two risers )

Output signal to actuators (Triac type)

24 VAC max. 1 A

Alarm signal output (Triac type)

24 VAC max. 1 A

Relay output

0-24 VAC/DC max. 1A

OC output (Transistor type)

0-20 VDC NPN Open collector max. 200 mA

Type of memory card (included)

SD

Maximum memory card

2 GB (included)

Timer: Real time clock

Built-in battery

powered for 10 years

Ambient temperature

0 … +50 °C

Transport temperature

–10 … +60 °C

IP rating

IP 20

Power supply

24 VAC

Power consumption

6 VA

Weight

0,9 kg

Installation

DIN rail 35 mm

ENGLISH
