21
2. Equipment connection and network setting
Refer to the following for confi guring or controlling the projector via a web browser.
Example: If the IP address of the projector is set to 192.168.1.10:
1) Enter
[http://192.168.1.10/] into the address
bar of the web browser and the screen
in Fig. 2.5.a will be displayed.
2) Enter your ID and password and click
[Logon] .
If the logon is successful either the Fig.2.5.b or Fig.2.5.c screen will be displayed.
3) Click the desired operation or confi guration item on the main menu located on
the left-hand side of the screen (Fig. 2.5.b or Fig. 2.5.c).
Fig. 2.5.b "Logon with administrator ID" Fig. 2.5.c "Logon with user ID"
Fig. 2.5.a "Logon Menu"
2.5 Confi guring and controlling the projector via a web browser (Continued)
