Setting Authorized Stations
33
Figure 6 Authorized Stations Add Window
4 In the Add dialog box, enter the IP address for the workstation you are
currently working from and click OK.
The Authorized Stations Completion window appears with the newly added IP
addresses listed.
Figure 7 Authorized Station Completion Window
For information about setting the network mask, refer to
Defining a Range of
IP Addresses for Authorized Access
later in this chapter.
5 Click Add to add additional entries for other workstations you want to grant
management access.
6 Repeat these steps for each device on your network.
7 If you changed the authorized stations on the Gatekeeper, SIP Proxy Server, or
any of the Back-end Servers, you must restart the SNMP agent. Refer to
