82 C HAPTER 7: P LACING , R ECEIVING AND D ISCONNECTING C ALLS
Creating a Connection
Script
You can choose to manually create a script from within a text editor of your choice
and copy and paste the script directly into the Script Configuration text box. Or
you may use the buttons located along the left side of the script window to guide
you through the scripting process.
Connection Script Command Syntax
The following section explains the valid script command syntax.
■
The Begin command (
begin
) initiates the script. The first line of the script must
start with begin .
■
The Delay command (
delay second) designates a length of time to wait before
sending the next command in the script. The acceptable values are between
1-60 seconds.
■
The SetPort command (
setport databit, parity, stopbit)
allows you to
match the script to the communication port settings of the remote server. The
valid databit is
8
or
7
. The valid parity is
none
,
even
, or
odd
. The valid stopbit is
either 1 or 2 .
■
The Transmit command (
transmit “text string” ) sends a text string to the
remote server. An example of a transmit string might be your account
username or password. This text must be included between the quotation
marks. A carriage return is simulated by the characters
^M within the quotation
marks . The maximum length for this string is 64 characters.
■
The WaitFor command (
waitfor “string, second”
) allows you to designate
the text that the script will wait for before proceeding. An example of text that
you might wait for is the string
Username
, for which you would send your
username as a reply. If the timeout period elapses before a matching string is
received, the script execution will abort. The maximum
string
length is 64
characters, and the acceptable second is between 1-60.
■
The End command completes your script. The last line of your script must
conclude with
end
.
Using the Configuration
Buttons
To create a connection script using the configuration buttons, do the following.
1 From the Script Configuration page, click Begin.
The text begin is entered as the first line in the script window.
2 Click Delay to set a delay interval before executing the next line of the script.
The Delay dialog box opens.
3 Enter the amount of time in seconds that your script will wait before proceeding.
This delay interval is used to allow the remote server time to process your request.
Click OK when finished.
The text delay xx is entered in the script window.
4 Click Set Port.
The Data Bits dialog box opens.
5 Enter the number of Data Bits required by your service provider. Click OK when
finished.
The Parity dialog box opens.
